1,499.00€ + KM
| Dimensions and weights | |
|---|---|
| Length approx. | 745 mm |
| Width/depth approx. | 565 mm |
| Height approx. | 935 mm |
| Weight approx. | 103 kg |
| Drilling/milling output | |
|---|---|
| Max. size milling head | 63 mm |
| Max. size shaft milling cutter | 20 mm |
| Drilling performance steel (S235JR) | 16 mm |
| Continuous drilling performance steel (S235JR) | 12 mm |
| Electrical Data | |
|---|---|
| Supply voltage | 230 V |
| Mains frequency | 50 Hz |
| Milling table horizontal | |
|---|---|
| Table length | 510 mm |
| Table width | 180 mm |
| Min. clearance vertical spindle – milling table | 0 mm |
| Max. clearance vertical spindle – milling table | 375 mm |
| T-groove size | 12 mm |
| T-groove number | 3 |
| T-groove spacing | 63 mm |
| Max. load bearing capacity | 50 kg |
| Travel | |
|---|---|
| X axis manual | 280 |
| Y axis manual | 175 mm |
| Z axis manual | 280 mm |
| Vertical spindle | |
|---|---|
| Reach | 185 mm |
| Spindle chuck | MT 2 / M 10 |
| Speed range | 90 – 1480 min¯¹ |
| Explanation speed range | M 10: 150 – 3000 min¯¹ |
| Number of gears | 2 |
| Speed control | electronically adjustable |
| Tightening bar | M 10 |
| Vertical spindle normal operation | 0.85 kW |
| Swivel range milling cutter head Z – X plane | ± 90 ° |
| Quill stroke | 50 mm |
1,499.00€ + KM
Add to Cart
