5,309.00€ + KM
| Dimensions and weights | |
|---|---|
| Length approx. | 970 mm |
| Width/depth approx. | 975 mm |
| Height approx. | 1025 mm |
| Weight approx. | 200 kg |
| Drilling/milling head | |
|---|---|
| Drill-mill head tilt range | ± 45 ° |
| Drilling/milling output | |
|---|---|
| Max. size milling head | 50 mm |
| Max. size shaft milling cutter | 25 mm |
| Electrical connections | |
|---|---|
| Total rated value | 2 kW |
| Electrical Data | |
|---|---|
| Supply voltage | 230 V |
| Mains frequency | 50 Hz |
| Fast motion speed | |
|---|---|
| X axis | 150 – 930 mm/min |
| Y axis | 100 – 580 mm/min |
| Z axis | 80 – 450 mm/min |
| Feed motor torque | |
|---|---|
| X axis continuous operation S1 | 2,2 Nm |
| Y axis continuous operation S1 | 2,2 Nm |
| Z axis continuous operation S1 | 4.2 nm |
| Feed speed | |
|---|---|
| X axis | 150 mm/min |
| Y axis | 100 mm/min |
| Z axis | 80 mm/min |
| Milling table horizontal | |
|---|---|
| Table length | 620 mm |
| Table width | 180 mm |
| Min. clearance vertical spindle – milling table | 0 mm |
| Max. clearance vertical spindle – milling table | 300 mm |
| T-groove size | 12 mm |
| T-groove number | 3 |
| T-groove spacing | 50 mm |
| Max. load bearing capacity | 30 kg |
| Standards and certifications | |
|---|---|
| Standard | DIN EN 55011 |
| EMC level | C2 |
| Travel | |
|---|---|
| X axis manual | 400 mm |
| Y axis manual | 210 mm |
| Z axis manual | 270 mm |
| X axis automatic | 380 mm |
| Y axis automatic | 130 mm |
| Z axis automatic | 190 mm |
| Vertical spindle | |
|---|---|
| Reach | 185 mm |
| Spindle chuck | BT 30 |
| Speed range | 200 – 4000 min¯¹ |
| Number of gears | 1 |
| Speed control | electronically adjustable |
| Vertical spindle normal operation | 1,5 kW |
| Vertical spindle drive motor torque | 10 nm |
