| Cross table | |
|---|---|
| Clearance vertical spindle – cross table | 250 mm |
| Dimensions and weights | |
|---|---|
| Length approx. | 504 mm |
| Width/depth approx. | 515 mm |
| Height approx. | 800 mm |
| Weight approx. | 58.5 kg |
| Drilling/milling head | |
|---|---|
| Drill-mill head tilt range | ±45 ° |
| Mill head swivel range | ± 90 ° |
| Drilling/milling output | |
|---|---|
| Max. size milling head | 50 mm |
| Max. size shaft milling cutter | 13 mm |
| Drilling performance steel (S235JR) | 13 mm |
| Continuous drilling performance steel (S235JR) | 11 mm |
| Electrical Data | |
|---|---|
| Drive motor output | 0.5 kW |
| Supply voltage | 230 V |
| Mains frequency | 50 Hz |
| Milling table horizontal | |
|---|---|
| Table length | 400 mm |
| Table width | 120 mm |
| T-groove size | 10 mm |
| T-groove number | 3 |
| T-groove spacing | 35 mm |
| Travel | |
|---|---|
| X axis manual | 240 mm |
| Y axis manual | 135 mm |
| Z axis manual | 150 mm |
| Vertical spindle | |
|---|---|
| Reach | 145 mm |
| Spindle chuck | MT 2 |
| Speed range | 90 – 2250 min¯¹ |
| Number of gears | 2 Steps |
| Speed control | electronically adjustable |
| Tightening bar | M10 |
| Quill diameter | 60 mm |
| Quill stroke | 50 mm |
